I. Pump Structure
Clamp-style connection design for easy installation and maintenance
Horizontal multistage segmental structure for space efficiency
Precision-cast impellers with hydrodynamically optimized design
II. Product Applications
Precision cooling systems for data centers
Constant temperature and humidity control for server rooms
Industrial circulating cooling systems
Thermal management systems for energy storage equipment
III. Product Features
High efficiency and energy saving: Optimized hydraulic model increases efficiency by over 15%
Low-noise operation: Quiet design with noise levels ≤65dB(A)
Smart monitoring: Supports IoT-based remote monitoring
Long service life: Key components made of stainless steel
Stable and reliable: Capable of 24-hour continuous operation
IV. Performance Parameters
Flow rate range: 5–200 m³/h
Head range: 30–200 m
Working pressure: ≤2.5 MPa
Medium temperature: 0–80°C
Protection class: IP55
V. Operating Conditions
Power supply: 380V/50Hz three-phase AC
Ambient temperature: -15°C to +40°C
Medium requirements: Clean, non-corrosive liquid
Installation method: Horizontal installation on a stable foundation
Recommended maintenance interval: Every 5,000 hours of operation
