Product Applications:

Primarily suitable for rural well water extraction, farmland irrigation, garden sprinkler systems, fountain installations, river water intake, aquaculture, and similar applications. (Not suitable for pumping muddy water, lime water, or corrosive liquids; must not be used to transport flammable, explosive, or highly volatile liquids, or liquids containing solid particles or fibers.)

Operating Conditions:

Maximum submersion depth: 10m
Maximum liquid temperature: 50°C
pH range: 6.5–8.5
Sand content (by volume) in the medium: ≤0.10%; particle size: ≤0.2mm

Electric Pump:

Wide voltage operating range: Single-phase pumps operate within 140V–270V; three-phase pumps operate within 310V–450V.
Compatible with photovoltaic (solar) power systems
IP68 protection rating
Insulation class: F

Product Features:

Equipped with a permanent magnet motor and variable frequency control for high energy efficiency
Compact structure: small size, lightweight, and easy to transport and install
Attractive appearance; constructed from stainless steel for durability
Multiple protection features (over-current, dry-run, over-voltage, locked-rotor, etc.) ensure safe operation
Excellent performance: high water output and high lift capability
Convenient operation with timing and constant-power running modes
