Water supply boosting for villas, residential complexes, schools, and small commercial facilities.
1. Pumped medium: Clean water or other liquids with similar properties.
2. pH value of the medium: 6.5–8.5.
3. Medium temperature: 0–60°C.
4. Volumetric ratio of impurities in the medium: ≤0.1%.
5. Power supply: 50 Hz frequency; single-phase AC 220 V; voltage fluctuation within ±10% of the rated value.
| Specifications and Model | Maximum flow rate (m³/h) |
Rated flow rate (m³/h) | Maximum head (m) | Rated head (m) | Rated Power (kW) | Rated voltage (V) | Maximum suction lift (m) | Pipe inner diameter (mm) | Rated current (A) | Gross Weight (kg) | Rotational speed (r/min) |
| PXm402 | 8 | 4 | 22 | 15 | 0.46 | 220 | 7 | 25 | 3.4 | 10.5 | 2850 |
| PXm403 | 8.4 | 4 | 33.5 | 25 | 0.55 | 220 | 7 | 25 | 3.9 | 11 | 2850 |
| PXm404 | 9 | 4 | 45 | 34 | 0.75 | 220 | 7 | 25 | 5.2 | 11.5 | 2850 |
| PX402 | 8 | 4 | 22 | 15 | 0.46 | 380 | 7 | 25 | 3.4 | 10.5 | 2850 |
| PX403 | 8.4 | 4 | 33.5 | 25 | 0.55 | 380 | 7 | 25 | 3.9 | 11 | 2850 |
| PX404 | 9 | 4 | 45 | 34 | 0.75 | 380 | 7 | 25 | 5.2 | 11.5 | 2850 |
| PX203E | 5 | 2 | 32 | 23.5 | 0.37 | 220 | 7 | 25 | 5.2 | / | 1000-3000 |
| PX404E | 9 | 4 | 45 | 32 | 0.75 | 220 | 7 | 25 | 7.2 | / | 1000-3000 |
