Tap water pipeline pressurization, garden irrigation, solar water system boosting, and greenhouse irrigation.
1. Ambient temperature: ≤ 40°C
2. Medium pH value: 6.5–8.5
3. Medium temperature: 0–90°C
4. Impurity content in the medium: ≤ 0.1% by volume; particle size: ≤ 0.2 mm
5. Power supply: 50 Hz frequency, single-phase AC 220 V; voltage fluctuation range: ±10% of rated value
| Specifications and Model | Maximum flow rate (m³/h) | Rated flow rate (m³/h) | Maximum head (m) | Rated head (m) | Rated Power (kW) | Rated voltage (V) | Maximum suction lift (m) | Pipe inner diameter (mm) | Rated current (A) | Gross Weight (kg) | Rotational speed (r/min) |
| PW125 | 2 | 1 | 24 | 10 | 0.125 | 220 | 8 | 20 | 1.0 | 8.3 | 2850 |
| PW250 | 2.2 | 1 | 30 | 14 | 0.25 | 220 | 8 | 25 | 1.9 | 9 | 2850 |
| PW370 | 2.4 | 1 | 36 | 16 | 0.37 | 220 | 8 | 25 | 2.7 | 9.3 | 2850 |
| PW550 | 3 | 1.5 | 42 | 18 | 0.55 | 220 | 8 | 25 | 3.9 | 12.1 | 2850 |
| PW750 | 3.4 | 1.5 | 50 | 20 | 0.75 | 220 | 8 | 25 | 5.2 | 13.8 | 2850 |
| PW1100 | 6 | 2.5 | 55 | 30 | 1.1 | 220 | 8 | 40 | 7.0 | 21.7 | 2850 |
| PW1100L | 6 | 2.5 | 55 | 30 | 1.1 | 220 | 8 | 40 | 7.0 | 26.3 | 2850 |
| PW125F | 2 | 1 | 24 | 10 | 0.125 | 220 | 8 | 20 | 1.0 | 8.3 | 2850 |
| PW250F | 2.2 | 1 | 30 | 14 | 0.25 | 220 | 8 | 25 | 1.9 | 9 | 2850 |
| PW370F | 2.4 | 1 | 36 | 16 | 0.37 | 220 | 8 | 25 | 2.7 | 9.3 | 2850 |
| PW550F | 3 | 1.5 | 42 | 18 | 0.55 | 220 | 8 | 25 | 3.9 | 12.1 | 2850 |
| PW750F | 3.4 | 1.5 | 50 | 20 | 0.75 | 220 | 8 | 25 | 5.2 | 13.8 | 2850 |
| PW1100Z | 6 | 2.5 | 55 | 30 | 1.1 | 220 | 8 | 40 | 7.0 | 21.7 | 2850 |
| PW1100ZL | 6 | 2.5 | 55 | 30 | 1.1 | 220 | 8 | 40 | 7.0 | 26.3 | 2850 |
