HVAC circulation systems, industrial circulation systems, solar hot water circulation systems, and domestic water pressure boosting.
1. Medium temperature: 2°C–100°C;
2. Ambient temperature: 0°C–40°C;
3. Maximum system pressure: 1.0 MPa;
4. Medium pH value: 6.5–8.5;
5. Impurity content in the medium: volume ratio ≤ 0.1%, particle size ≤ 0.2 mm;
6. Installation method: Horizontal installation (aligned with the motor shaft);
| Specifications and Model | Maximum flow rate (m³/h) | Rated flow rate (m³/h) | Maximum head (m) | Rated head (m) | Rated Power (kW) | Rated voltage (V) | Pipe inner diameter (mm) | Rated current (A) | Gross Weight (kg) | Rotational speed (r/min) |
| CPH10-40F | 9 | 5 | 5.5 | 4 | 0.24 | 220 | 40 | 0.9 | 8.9 | 2850 |
| CPH12-50F | 15 | 8 | 6 | 4.5 | 0.3 | 220 | 50 | 1.3 | 12.8 | 2850 |
| CPH25-40F | 8 | 4 | 15 | 11 | 0.45 | 220 | 40 | 1.8 | 10.3 | 2850 |
| CPH25-50F | 18 | 11 | 8 | 5 | 0.41 | 220 | 50 | 1.9 | 19 | 2850 |
| CPH40-50F | 21 | 10 | 17 | 10 | 0.9 | 220 | 50 | 3.0 | 26.5 | 2850 |
| CPH110-50F | 24 | 13 | 20 | 13 | 1.5 | 220 | 50 | 7.0 | 28 | 2850 |
| CPHS150-40F | 30 | 15 | 25 | 15 | 2.1 | 380 | 40 | 3.4 | 37.5 | 2850 |
| CPHS220-40F | 36 | 18 | 30 | 20 | 2.9 | 380 | 40 | 4.8 | 40 | 2850 |
